TX120 S3 Upgrade and Maintenance Manual 175
Expansion cards and backup units
Expansion card overview
I For the latest information on supported expansion cards, refer your
server’s hardware configurator available online at the following address:
for the EMEA market:
http://ts.fujitsu.com/products/standard_servers/tower/primergy_tx120s3.html
Expansion Card Slot number priority
Type Vendor Model
Max.
#.
Slot 2
PCIe x1
Slot 3
PCIe x4
Slot 4
PCIe x16
SATA Onboard Intel C202 Chipsatz - - - -
SATA
RAID
Onboard LSI
MegaSR
Intel C202 Chipsatz - - - -
SAS
LSI
LSI SAS IME D2507-D
(LSI 1064)
12 1 3
LSI
LSI SAS IME
D2507-C (LSI 1068)
13 1 2
LSI SAS RAID 9200-8E 1 3 1 2
LSI SAS RAID 9280 1 3 2 1
FTS
LSI MegaRAID SAS
D2607-A
11 2 3
FTS
LSI MegaRAID SAS
D2607-A
11 2 3
LAN
Onboard Intel Intel 82579LM - - - -
Onboard Intel Intel 82574L - - - -
Intel
PRO/1000CT Desktop
Adapter
13 2 1
Intel
Dual Port FJ D2735
Server Adapter
23 2 1
Intel
Quad Port FJ D2745
Server Adapter
23 2 1
Intel Intel 10GB 2 1 2 3
Video
ServerEngines
Onboard iRMC S3
(Matrox G200e)
----
Nvidia Quadro NVS300 1 1 - -
Misc
Sunrich
Technology
USB3.0 PCIe x1
adapter card
11
Table 5: Expansion card slot sequence
