TX120 S3 Upgrade and Maintenance Manual 363
15 Cables
This chapter provides information on how to connect, disconnect and route
cables.
Safety notes
V CAUTION!
● Always hold cables by their connectors when disconnecting them.
Never pull on the cable to disconnect cables.
● Ensure that none of the cables are scraped, strained or otherwise
damaged while replacing system components.
● Immediately replace cables with damaged shielding.
● Always use shielded network cables.
In this chapter
● "Overview of used cables" on page 364
● "Cabling" on page 365
● "Replacing the front panel cable" on page 373
● "Replacing the power cable" on page 380
● "Replacing SAS / SATA cables" on page 397
● "Replacing the backup drive USB cable" on page 404
● "Replacing BBU cables" on page 411
● "Replacing the front LAN cable" on page 410
I For a complete cabling overview, please refer to section "Cabling" on
page 365.
Field Replaceable Units (FRU)
