34 Upgrade and Maintenance Manual TX120 S3
Before you start
2.4 Documents you need at hand
Maintenance procedures may include references to additional documentation.
When preparing the maintenance task, ensure that all required manuals are
available according to the overview below.
I – Ensure to store all printed manuals enclosed with your server in a
save place for future reference.
– Unless stated otherwise, all manuals are available online at
http://manuals.ts.fujitsu.com under Industry standard servers or from the
ServerView Suite DVD 2 supplied with your PRIMERGY server.
For the Japanese market please use the following address:
http://jp.fujitsu.com/platform/server/primergy/manual/
Phillips
PH1 / (+) No. 1
TFM module M2.5 x 4 mm
(silver)
C26192-Y10-
C103
Phillips
PH2 / (+) No. 2
USB 3.0
interface
card D3305
M3 x 5 mm
(silver)
(contained in card
kit S26361-D3305-
A10)
Document Description
"Quick Start Hardware -
PRIMERGY Server TX120 S3"
leaflet
" はじめにお読みください -
PRIMERGY TX120 S3 " リーフ
レット for the Japanese market
Quick installation poster for initial operation,
available only in printed form
Table 4: Documentation you need at hand
Screw driver /
Bit insert
Screw Usage Type
Table 3: List of required tools and used screws
