Fujitsu PRIMERGY TX120 S3 - Front LAN Connector; Installing the Front LAN Connector; Required Tools; Preliminary Steps

300 Upgrade and Maintenance Manual TX120 S3
Front panel and LAN connector
13.2 Front LAN connector
13.2.1 Installing the front LAN connector
13.2.1.1 Required tools
● Preliminary and concluding steps: tool-less
● Replacing the front LAN connector:
– Phillips PH2 / (+) No. 2 screw driver
13.2.1.2 Preliminary steps
Before replacing the front LAN connector, perform the following steps:
Ê Disable BitLocker functionality as described in section "Disabling BitLocker
functionality" on page 79.
Ê Locate the defective server as described in section "Locating the defective
server" on page 50.
Ê Shut down the server as described in section "Shutting down the server" on
page 58.
Ê Disconnect the AC power cord from the system.
Ê Remove the server cover as described in section "Opening the server" on
page 61.
Field Replaceable Units (FRU)
Average task duration: 10 minutes
