TX120 S3 Upgrade and Maintenance Manual 277
Accessible drives
Figure 157: Inserting the ODD filler cover.
Ê Insert the ODD filler cover into the resess on the right side (1).
Ê Fold the ODD filler cover back (2).
12.2.2.4 Concluding steps
Perform the following procedures to complete the task:
Ê Close the front cage as described in "Closing the front cage" on page 68.
Ê Close the server cover as described in section "Closing the server" on
page 70.
Ê Reconnect the AC power cord to the power supply unit.
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task, re-enable BitLocker as described in section "Enabling
BitLocker functionality" on page 103.
/
