TX120 S3 Upgrade and Maintenance Manual 407
Cables
15.7.4 Installing the backup drive USB cable
Figure 265: Installing the backup drive USB cable (A)
Ê Reconnect the new USB cable (Type B connector) to the backup drive.
Ê Run the backup drive USB cable through the cable clamps.
