Fujitsu PRIMERGY TX120 S3 - Configuration Tables; Mounting Order for Hard Disk Drives; Solid State Drives; Memory Board Configuration; Expansion Card Configuration Table

426 Upgrade and Maintenance Manual TX120 S3
Appendix
16.2 Configuration tables
16.2.1 Mounting order for Hard disk drives / solid state
drives
Please refer to chapter "Hard disk drives / solid state drives" on page 119.
16.2.2 Memory board configuration
Please refer to chapter "Main memory" on page 233.
16.2.3 Expansion card configuration table
Please refer to chapter "Expansion cards and backup units" on page 173.
8 Battery backup unit "Replacing a BBU" on page 207
9 HDD / SSD drive bay "Hard disk drives / solid state drives" on
page 119
10 Front panel module bay "Replacing expansion cards" on page 183
11 Accessible drive bay "Replacing the system fan module" on
page 154
12 System board D3049 "Replacing the system board" on page 346
13 Memory modules "Replacing memory modules" on
page 241
14 Standard power supply
unit
"Replacing the standard power supply unit"
on page 112
Pos. Component Reference
