Fujitsu PRIMERGY TX120 S3 - Server Interior

TX120 S3 Upgrade and Maintenance Manual 425
Appendix
16.1.3 Server interior
Figure 281: PRIMERGY TX120 S3 interior (2.5-inch HDD / standard PSU model)
Pos. Component Reference
1System fan "Replacing the system fan module" on
page 154
2 Expansion card slots "Replacing expansion cards" on page 183
3 Processor / CPU heat
sink
"Replacing the processor" on page 246
4 TPM board "Replacing the TPM board" on page 343
5 CMOS battery "Replacing the CMOS battery" on
page 314
6 UFM board "Replacing the UFM board" on page 325
7 SAS / SATA HDD / SSD
backplane
"Replacing SAS / SATA backplane" on
page 143
/
