TX120 S3 Upgrade and Maintenance Manual 137
Hard disk drives / solid state drives
7.3.3 Removing 3.5-inch HDD modules
7.3.3.1 Required tools
● Preliminary and concluding steps: tool-less
● Removing a 3.5-inch HDD module: tool-less
7.3.3.2 Preliminary steps
Before removing a 3.5-inch HDD module, perform the following steps:
Ê Ensure that the HDD module to be removed is not combined into a RAID
array. If the drive is part of a RAID array, you first need to delete the array
using ServerView RAID Manager.
V CAUTION!
All data on all HDDs in the array will be lost! Be sure to back up your
data before deleting a RAID array.
I For further information, please refer to the "ServerView Suite RAID
Management" user guide, available online at
http://manuals.ts.fujitsu.com (EMEA market) or
http://jp.fujitsu.com/platform/server/primergy/manual/ (Japanese
market) or from the ServerView Suite DVD 2 supplied with your
PRIMERGY server.
Ê Shut down the server as described in section "Shutting down the server" on
page 58
Ê Remove the server cover as described in section "Opening the server" on
page 61
Ê Open the front cage as described in section "Opening the front cage" on
page 66.
Upgrade and Repair Units (URU)
Average task duration: 5 minutes
