TX120 S3 Upgrade and Maintenance Manual 215
Expansion cards and backup units
9.4 Additional tasks
This section provides additional expansion card related information on how to
install slot brackets and SFP+ transceiver modules.
I For further instructions regarding controller settings, please refer to the
accompanying documentation.
9.4.1 Mounting expansion card slot brackets
This section provides general instructions on mounting slot brackets as well as
specific instructions for the following network adapters:
● "Network adapter D2735" on page 217
● "Network adapter D2745" on page 219
● "Network adapter D2755" on page 221
● "USB 3.0 interface card D3305" on page 223
9.4.1.1 Required tools
● Preliminary and concluding steps: tool-less
● Mounting slot brackets:
– Phillips PH2 / (+) No. 2 screw driver
Customer Replaceable Units (CRU)
Average task duration: 5 minutes
To Next Page
