TX120 S3 Upgrade and Maintenance Manual 125
Hard disk drives / solid state drives
7.2.3 Removing 2.5-inch HDD / SSD modules
7.2.3.1 Required tools
● Preliminary and concluding steps: tool-less
● Removing a 2.5-inch HDD / SSD module: tool-less
7.2.3.2 Preliminary steps
Before removing a 2.5-inch HDD / SSD module, perform the following steps:
Ê Ensure that the HDD / SSD module to be removed is not combined into a
RAID array. If the drive is part of a RAID array, you first need to delete the
array using ServerView RAID Manager.
V CAUTION!
All data on all HDDs / SSDs in the array will be lost! Be sure to back
up your data before deleting a RAID array.
I For further information, please refer to the "ServerView Suite RAID
Management" user guide, available online at
http://manuals.ts.fujitsu.com (EMEA market) or
http://jp.fujitsu.com/platform/server/primergy/manual/ (Japanese
market) or from the ServerView Suite DVD 2 supplied with your
PRIMERGY server.
Ê Remove the hard disk drive cover as described in section "Removing the
hard disk drive cover" on page 65.
Customer Replaceable Units (CRU)
Average task duration: 5 minutes
