322 Upgrade and Maintenance Manual TX120 S3
System board and components
14.2.1.5 Software configuration
The UFM delivery set includes the "Recovery Tool CD" to setup the VMware
ESXi configuration. Proceed as follows:
Ê Switch on the server.
Ê Right after switching on the server, insert the "Recovery Tool CD" into the
DVD drive and close the drive tray.
Ê The server should now boot from the "Recovery Tool CD".
Ê Follow the on-screen instructions.
14.2.2 Removing the UFM board
14.2.2.1 Required tools
● Preliminary and concluding steps:
– Phillips PH2 / (+) No. 2 screw driver
● Removing the UFM:
– Phillips PH1 / (+) No. 1 screw driver
14.2.2.2 Preliminary steps
Before removing the UFM board, perform the following steps:
Ê Disable BitLocker functionality as described in section "Disabling BitLocker
functionality" on page 79.
Ê Locate the defective server as described in section "Locating the defective
server" on page 50.
Ê Shut down the server as described in section "Shutting down the server" on
page 58.
Ê Disconnect the AC power cord from the system.
Field Replaceable Units (FRU)
Average task duration: 5 minutes
