240 Upgrade and Maintenance Manual TX120 S3
Main memory
10.3.3 Removing a memory module
Ê Identify the desired memory slot according to the mounting order described
in section "Memory sequence" on page 234.
V CAUTION!
Ensure to maintain an operational configuration when removing
memory modules. For additional information, please refer to section
"Operation modes" on page 235.
Figure 131: Removing memory modules
Ê Eject the desired memory module by pressing out the securing clips at each
end of the memory module connector.
Ê Remove the ejected memory module.
