198
Upgrade and Mai
ntenance Manual
TX120
S3
Exp
ansion cards and backup un
it
s
9.3.2.3
Inst
alling TF
M to the RAID controller (if ap
plicable)
Figure 93: TFM kit
Figure 94: Instal
ling TFM
Ê
Fit the spacer bolt
s of the TFM on the RAID controller (1).
Ê
Fasten the
TFM on the
RAID controller with the
three screws fr
om the TFM
kit (screw torque: 0.4 Nm)(2).
1T
F
M
2S
c
r
e
w
s
197
