222
Upgrade and Mai
ntenance Manual
TX120
S3
Exp
ansion cards and backup un
it
s
Figure 1
15: Network adapter
D2755 - M
ounting the slot brac
ket (B)
Ê
Secure the slot bracket to the controller with two M3 x 4.5 mm screws.
Figure 1
16: Network adapter
D2755 - M
ounting the slot brac
ket (C)
I
Assembled network adapter D2755
221
223
