24 Upgrade and Maintenance Manual TX120 S3
Introduction
Model lines for TX120 S3
There are two model lines for the TX120 S3 server:
– TX120 S3
– TX120 S3p
The following table provides an overview of the different features:
I For the European market:
You can identify the model line by the model name "TX120 S3p" printed
on the identification rating plate and on the ID card.
I For the Japanese market:
"TX120 S3p" is not used as the model name in the Japanese market.
You can identify the model line by the product number; The product
number "PYT12Pxxx" means TX120 S3p.
TX120 S3 TX120 S3p
System board D3049-Axx D3049-Bxx
Processors Intel
®
XEON
®
E3-1200 processor
series
Intel
®
Pentium
®
/ Celeron
®
processor series
Intel
®
Coreâ„¢ i3-2100 processor
series
Intel
®
XEON
®
E3-1200v2
processor series
Intel
®
Pentium
®
/ Celeron
®
processor series
Intel
®
Coreâ„¢ i3
processor series
Main Memory DDR3 UDIMM with 1333 MHz
speed
up to 21 GB/s bandwidth in dual
channel mode and 10.6 GB/s in
single channel mode
DDR3 UDIMM with 1600 MHz
speed
up to 25.6 GB/s bandwidth in dual
channel mode and 12.8 GB/s in
single channel mode
PCI slots 1x PCI 3.0 (32 Bit / 33MHz)
1x PCIe x16 Gen 2
1x PCIe x4 Gen 2
(mechanical x8)
1x PCIe x1 Gen 2
(mechanical x4 notched)
1x PCI 3.0 (32 Bit / 33MHz)
1x PCIe x16 Gen 3
1x PCIe x4 Gen 2
(mechanical x8)
1x PCIe x1 Gen 2
(mechanical x4 notched)
Table 1: Differences between TX120 S3 and TX120 S3p
