428 Upgrade and Maintenance Manual TX120 S3
Appendix
2 PC2009 Power supply connector
3 Reset Connector for RESET switch
4 Frontpanel
USB
Front panel /USB connector
5 SATA POWER Power supply connector
6 FRONT LAN Connector for LAN on the front side
7 FAN2 SYS Connector for system fan 2
8 FAN1 CPU Connector for CPU fan
9 SATA MLC1 SATA MLC connector (4 port)
10 HDD ACTIVITY Connector for HDD activity LED
11 USB1 AUX USB connector (only for internal USB devices)
12 USB1 DAT USB connector (only for internal USB devices)
13 Intrusion Intrusion connector
14 UFM Connector for USB Flash Module (UFM)
15 SATA 6 SATA 6 connector
16 SATA 5 SATA 5 connector
17 TPM Connector for TPM
18 FAN1 SYS Connector for system fan 1
No. Print Description
