Fujitsu PRIMERGY TX2540 M1 Upgrade And Maintenance Manual

TX2540 M1 Upgrade and Maintenance Manual 105
Basic software procedures
I For the Japanese market, follow the instructions provided separately.
Note on Cool-safe
®
Advanced Thermal Design (ATD)
I If the Cool-safe
®
Advanced Thermal Design (ATD) option is available
and has been enabled for your server, please set information within the
Chassis ID Prom Tool accordingly.
V CAUTION!
Please note that you can only set the ATD flag. Resetting the ATD flag
using the Chassis ID Prom Tool is not possible!
5.2.18 Configuring LAN teaming
Use ServerView Operations Manager to obtain detailed information on existing
LAN teams:
Ê In ServerView Operations Manager Single System View select System Status
from the Information / Operation menu.
Ê Under Network Interfaces select LAN Teaming.
Ê The Network Interfaces (Summary) overview shows all configured LAN teams
and their components. Choose a LAN team to display further details:
– LAN Team Properties: Properties of the selected LAN team
– LAN Team Statistics: Available statistics about the selected LAN team
I For more detailed information, refer to the "ServerView Operations
Manager - Server Management" user guide.
5.2.18.1 After replacing / upgrading LAN controllers
Please note when re-using a replaced LAN controller:
The ATD option can only be ordered from the manufacturer
as a factory preset. To find out if your server is ATD-
enabled, check for the ATD logo on the identification rating
plate.
For further information on Cool-safe
®
Advanced Thermal
Design (ATD), please refer to your server’s operating
manual.

Fujitsu PRIMERGY TX2540 M1 Specifications

General

Processor socket	-
Intel Xeon series	E5-2400
Built-in processor	No
Motherboard chipset	Intel® C602
Number of processors supported	2
Number of DIMM slots	12
Supported memory types	DDR3-SDRAM
Maximum internal memory	192 GB
RAID levels	0, 1, 10
Hot-swap HDD bays	Yes
Storage drive sizes supported	3.5 \
Number of storage drives supported	4
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	6
Chassis type	Tower
Product color	Black
