7.5.2 Removing the SAS expander board
7.5.2.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 77
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 48
Ê "Getting access to the component" on page 49
Ê "Removing the system fan holder" on page 74
7.5.2.2 Removing the SAS expander board
Ê Remove all cables from the SAS expander board except the two SAS cables
connected to connectors "X5" and "X6" on the SAS expander board.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less
