Expansion cards and backup units
9.2 Handling slot brackets
9.2.1 Installing a slot bracket
I Use the full height bracket perforated for the ModularRAID controllers
based on LSI MegaRAID.
Figure 140: Perforated and non-perforated slot brackets
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
1 Full height bracket non-perforated
2 Full height bracket perforated
3 Low profile bracket perforated
