Fujitsu PRIMERGY TX2540 M1

TX2540 M1 Upgrade and Maintenance Manual 117
Power supply units
Figure 41: Removing the installation frame (B)
Ê Remove the installation frame from the power supply unit.
6.2.1.3 Installing the new standard power supply unit
Figure 42: Installing the installation frame (A)
Ê Fit the installation frame to the power supply unit.
Ê Ensure that the installation frame is correctly seated on the power supply
unit.
