7.4 HDD extension boxes
I The procedures for the HDD extension boxes are identic except of
cabling and required bays.
7.4.1 HDD extension box variants
8x 2.5-inch HDD extension box
Figure 107: 8x 2.5-inch HDD extension box - Rack version
Figure 108: 8x 2.5-inch HDD extension box - Tower version
I The 8x 2.5-inch HDD extension box occupies accessible drive bays 2
and 3.
