12.5.3 Replacing a slimline ODD or LSD
12.5.3.1 Preliminary steps
Ê "Locating the defective server" on page 45
Ê "Removing backup and optical disk media" on page 80
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 48
Ê "Getting access to the component" on page 49
I Removing the front cover is not required in order to replace the
slimline ODD or LSD module in the Multibay box.
Ê "Removing the system fan holder" on page 74
Ê "Removing the Multibay box" on page 316
12.5.3.2 Removing the defective slimline ODD
Ê Remove the slimline ODD from the Multibay box as described in section
"Removing the slimline ODD" on page 317.
12.5.3.3 Removing the defective LSD module
Ê Remove the LSD module from the Multibay box as described in section
"Removing the LSD module" on page 319.
12.5.3.4 Installing the new slimline ODD
Ê Install the slimline ODD into the Multibay box as described in section
"Installing the slimline ODD" on page 309.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
