17.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 48
Ê Take the system down to its minimum startup configuration.
Ê "Connecting the server to the mains" on page 72
Ê Connect a keyboard, mouse and display to the server.
Ê Switch on the server as described in section "Switching on the server" on
page 73.
Field Replaceable Units (FRU)
Component Notes and reference
System board no TPM, UFM or expansion cards installed
1 CPU with CPU heat sink installed in socket CPU 1
1 memory module installed in DIMM slot 1A
Front panel module
1 Power supply module installed in PSU bay 1
Table 6: Minimum startup configuration - components
Cable Notes and reference
Front panel cable
Power cable
Table 7: Minimum startup configuration - cables
