17.2.1.2 Onboard indicators and controls
Figure 317: Onboard indicators and Indicate CSS button
Component LEDs
I LEDs A, B and C are visible from the outside on the server rear. All other
LEDs are only visible if the server cover has been opened.
1 Indicate CSS button
Indicator Status Description
A ID indicator blue on
server has been highlighted using
ServerView Operations Manager,
iRMC web frontend, or the ID button on
the front panel for easy identification
