The hooks on the air duct will lock in the narrow ends of the keyhole slots on
the FBU holder.
Ê Ensure that the locking handle on the FBU holder properly snaps in place
(2).
Ê If applicable, install a RAID controller as described in section "Installing
expansion cards" on page 231.
Ê Connect the FBU cable to the TFM (3, see close-up).
9.5.3.4 Concluding steps
Ê "Reassembling" on page 62
Ê "Connecting the server to the mains" on page 72
Ê "Switching on the server" on page 73
Ê If applicable, "Updating RAID controller firmware" on page 88
Ê "Enabling SVOM boot watchdog functionality" on page 96
9.5.4 Removing a BBU
V CAUTION!
Do not throw battery backup units into the trash can. Batteries must be
disposed of in accordance with local regulations concerning special
waste.
For further safety information, please refer to section "Environmental
protection" on page 42.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
