Hard disk drives / solid state drives
7.5 SAS expander board
7.5.1 Installing the SAS expander board
7.5.1.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 77
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 48
Ê "Getting access to the component" on page 49
Ê "Removing the system fan holder" on page 74
7.5.1.2 Installing the carrier
Figure 121: Position for the carrier
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver (for installing the carrier)
