Cabling
16.1 List of used cables
I The numbers in the cable list correspond to those shown in the cabling
plans.
No. Name
Part number
(T26139-)
Routing
C1 HDD Power cable Y4030-V102
Power backplane to system board and
SAS backplane
C2 CBL_PDB_MoBo_Pow14 Y3952-V511 Power backplane to system board
C3 CBL_PDB_MoBo_Pow12 Y4030-V2 Power backplane to system board
C4 CBL_PDB_MoBo_Sig10 Y3956-V2 Power backplane to system board
C5 CBL_MoBo_DVD Y3939-V301
ODD to system board or SAS
backplane
C6
HDD extension box power
cable
Y3939-V402 System board to HDD extension box
C7
HDD extension box power
cable
Y3939-V401 System board to HDD extension box
C10 CBL_FRONTPANEL 650 Y4015-V2 Front panel module to system board
C12 CBL_INTRUSION_SW_New Y3922-V121 Server side and front to system board
C17 CBL_LSD 700 Y3718-V301 LSD to system board
C20 CBL_SAS470x1 Y3963-V103 SAS backplane to SAS controller
C21 CBL_SAS36TO36 Y3963-V117 SAS backplane to SAS controller
C22 CBL_BBU08 160 Y3987-V3 BBU to SAS controller
C22 CBL_FBU 170 Y4032-V3 FBU to TFM
C23 CBL_DVD Y3928-V205 System board to DVD
C32 CBL_SATA_Full_Pow410 Y3930-V601 SATA power cable (standard)
C33 CBL_SATA_Slim_Pow400 Y3986-V302 SATA power cable (slim)
C34 CBL_SAS_Dev_PowSig700 Y3969-V401
SAS power cable; for LTO3 power
must be connected to C35
C35 CBL_PATA_Dev_Pow410 Y4029-V1 PATA power cable
C37 USB 3.0 cable Y4039-A80
USB backup drive to USB3.0 interface
card
C42
CBL_SASEXP_HDD cage
bottom
Y4040-V4
SAS expander board to SAS
bac
kplane
Table 5: List of used cables
