Fujitsu PRIMERGY TX2540 M1

338 Upgrade and Maintenance Manual TX2540 M1
Front panel module
Figure 250: Removing the front panel cable
Ê Remove the front panel cable from the defective front panel module as
shown.
13.1.3 Installing the new front panel module
Figure 251: Connecting the front panel cable
Ê Connect the front panel cable to the new front panel module as shown.
