Figure 257: UFM mounting location
Figure 258: Installing the UFM
Ê Connect the UFM to the system board (1), snapping in the UFM spacer.
Ê Fasten the nylon screw (2).
14.3.1.3 Concluding steps
Ê "Reassembling" on page 62
Ê "Connecting the server to the mains" on page 72
Ê "Switching on the server" on page 73
Ê "Enabling SVOM boot watchdog functionality" on page 96
Ê "Enabling BitLocker functionality" on page 101
