Fujitsu PRIMERGY TX2540 M1

166 Upgrade and Maintenance Manual TX2540 M1
Hard disk drives / solid state drives
7.3.2 4x 3.5-inch HDD configuration
Mounting order
Figure 89: Mounting order with up to 4 3.5-inch HDDs (1 SAS backplane)
HDD / SSD naming scheme
Figure 90: Naming scheme with 4 3.5-inch HDDs (1 SAS backplane)
Position
Logical drive
number
ServerView RAID Manager display name
[1] 0 HDD vendor name (0)
[2] 1 HDD vendor name (1)
[3] 2 HDD vendor name (2)
[4] 3 HDD vendor name (3)
