14.3.3 Replacing the UFM
14.3.3.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 77
Ê "Disabling SVOM boot watchdog functionality" on page 78
Ê "Locating the defective server" on page 45
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 48
Ê "Getting access to the component" on page 49
14.3.3.2 Removing the defective UFM
Ê Remove the UFM from the system board as described in section "Removing
the UFM" on page 347.
Ê The UFM spacer remains on the system board.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
– combination pliers and flat nose pliers
