12.5.3.5 Installing the new LSD module
Ê Install the LSD module into the Multibay box as described in section
"Installing the LSD module" on page 312.
12.5.3.6 Concluding steps
Ê "Installing the Multibay box" on page 313
Ê "Installing the system fan holder" on page 75
Ê "Reassembling" on page 62
Ê "Connecting the server to the mains" on page 72
Ê "Switching on the server" on page 73
Ê If applicable, "Verifying and configuring the backup software solution" on
page 90
12.6 Slimline ODD in 4x 3.5-inch HDD extension
box
12.6.1 Installing the slimline ODD
12.6.1.1 Preliminary steps
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 48
Ê "Getting access to the component" on page 49
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
