I The chipset offers two integrated USB 2.0 Rate Matching Hubs (RMHs).
that enable lower power requirements and manages the transition of the
communication data rate from the high speed of the host controller to the
lower speed of USB full speed / low speed devices.
17.2.1.4 I/O panel indicators
Figure 319: I/O panel indicators
Indicator Status Description
1
Global error
indicator
off no critical event (non-CSS component)
orange on
prefailure detected (non-CSS
component)
orange flashing non CSS component failure
CSS
indicator
off no critical event (CSS component)
yellow on prefailure detected (CSS component)
yellow flashing CSS component failure
ID indicator blue on
server has been highlighted using
ServerView Operations Manager, iRMC
web frontend, or the ID button on the front
panel for easy identification
2
LAN
link / transfer
indicator
green on LAN connection established
off no LAN connection
green flashing data transfer in progress
