I Note on the onboard LAN controller
The separate management LAN connector is used as a management
interface (iRMC S4) and is prepared for operation with the Remote
Management. Optionally LAN connector 1 can also be used for iRMC S4
server management.
iRMC-related status signals
3
LAN speed
indicator
yellow on traffic a transfer rate of 1 Gbit/s
green on traffic a transfer rate of 100 Mbit/s
off traffic a transfer rate of 10 Mbit/s
ID indicator
Global error
indicator
Description
blue flashing off
A remote connection has been
established. Local VGA output has
been disabled during the remote
session.
blue flashing orange flashing
An emergency flash of the iRMC
firmware is in progress.
Indicator Status Description
