10.1 Basic information
Figure 183: Memory overview
– The system board is equipped with 12 memory slots (6 memory slots per
CPU)
– The system has to be equipped with at least one memory module per CPU.
– Supported capacities: 4 GB, 8 GB, or 16 GB
– Maximum amount of RAM: 192 GB
– Supported memory modules:
DDR3-1600 PC3-12800
Type Ranking
Error
Correction
SR: Single-Rank, DR: Dual-Rank SR DR
RDIMMs (Registered DIMMs) o o
ECC or non-
ECC
