Fujitsu PRIMERGY TX2540 M1 Upgrade And Maintenance Manual

TX2540 M1 Upgrade and Maintenance Manual 259
Expansion cards and backup units
9.5.6 Replacing a BBU
V CAUTION!
Do not throw battery backup units into the trash can. Batteries must be
disposed of in accordance with local regulations concerning special
waste.
For further safety information, please refer to section "Environmental
protection" on page 42.
9.5.6.1 Preliminary steps
Ê "Locating the defective server" on page 45
Ê "Disabling SVOM boot watchdog functionality" on page 78
Ê "Shutting down the server" on page 48
Ê "Disconnecting the server from the mains" on page 48
Ê "Getting access to the component" on page 49
9.5.6.2 Removing the defective BBU
Ê Remove the BBU as described in section "Removing the BBU" on page 254.
9.5.6.3 Installing the new BBU
Ê Install the BBU as described in section "Installing the BBU" on page 245.
9.5.6.4 Concluding steps
Ê "Reassembling" on page 62
Ê "Connecting the server to the mains" on page 72
Ê "Switching on the server" on page 73
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less

Fujitsu PRIMERGY TX2540 M1 Specifications

General

Processor socket	-
Intel Xeon series	E5-2400
Built-in processor	No
Motherboard chipset	Intel® C602
Number of processors supported	2
Number of DIMM slots	12
Supported memory types	DDR3-SDRAM
Maximum internal memory	192 GB
RAID levels	0, 1, 10
Hot-swap HDD bays	Yes
Storage drive sizes supported	3.5 \
Number of storage drives supported	4
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	6
Chassis type	Tower
Product color	Black
