Fujitsu PRIMERGY TX2540 M1

406 Upgrade and Maintenance Manual TX2540 M1
Appendix
3.5-inch HDD model
Figure 313: Front side - 3.5-inch HDD model
17.1.2 Server rear
Figure 314: Rear side
1
3.5-inch hard disk drives /
dummy modules
3
4x 3.5-inch HDD extension box
with LSD or slimline ODD bay
2 ID card 4 Front panel module
1 Power supply unit (photo shows the standard power supply unit)
2 I/O panel
3 Optional expansion cards
