Fujitsu PRIMERGY TX2540 M1

TX2540 M1 Upgrade and Maintenance Manual 405
17 Appendix
17.1 Mechanical overview
17.1.1 Server front
2.5-inch HDD / SSD model
Figure 312: Front side - 2.5-inch HDD / SSD model
1
2.5-inch hard disk drives / solid
state drives / dummy modules
4
Optical disk drive /
5.25-inch dummy module
2 8x 2.5-inch HDD extension box 5 Front panel module
3ID card
