Hard disk drives / solid state drives
7.3 3.5-inch HDD configurations
7.3.1 3.5-inch HDD backplane overview
Figure 87: 3.5-inch SAS backplanes - maximum configuration, rack server
Figure 88: 3.5-inch SAS backplanes - maximum configuration, tower server
1 SAS backplane 1 in HDD cage 1 (basic configuration)
2 SAS backplane 2 in optional 4x 3.5-inch HDD extension box
