Fujitsu PRIMERGY TX2540 M1

TX2540 M1 Upgrade and Maintenance Manual 139
Hard disk drives / solid state drives
7.2 2.5-inch HDD / SSD configurations
7.2.1 2.5-inch HDD backplane overview
Figure 60: 2.5-inch SAS backplanes - maximum configuration, rack version
Figure 61: 2.5-inch SAS backplanes - maximum configuration, tower version
1 / 2 SAS backplanes 1 and 2 in HDD cage 1 (basic configuration)
3 / 4 SAS backplanes 3 and 4 in optional HDD cage 2
5 / 6 SAS backplanes 5 and 6 in optional 8x 2.5-inch HDD extension box
