Fujitsu PRIMERGY TX2540 M1

182 Upgrade and Maintenance Manual TX2540 M1
Hard disk drives / solid state drives
4x 3.5-inch HDD extension box
Figure 109: 4x 3.5-inch HDD extension box - Rack version
Figure 110: 4x 3.5-inch HDD extension box - Tower version
I The 4x 3.5-inch HDD extension box occupies accessible drive bays 1, 2
and 3. This box can also be equipped with a slimline ODD.
Bays 1-3
Bays 1-3
