Fujitsu PRIMERGY TX2540 M1

TX2540 M1 Upgrade and Maintenance Manual 219
Expansion cards and backup units
Expansion card slot sequence
I For the latest information on supported expansion cards, refer to your
server’s hardware configurator available online at the following address:
for the EMEA market:
http://ts.fujitsu.com/products/standard_servers/index.htm
for the Japanese market:
http://jp.fujitsu.com/platform/server/primergy/system/
PCI
32/33
PCIe
x4
PCIe
x4
PCIe
x16
PCIe
x4
PCIe
x16
PCH PCH CPU1 CPU1 CPU1 CPU2
Rule
#
PCI controller max. Slot1 Slot2 Slot3 Slot4 Slot5 Slot6
1 RAID Ctrl SAS 6G 0/1
(D2607)
1----1-
2 RAID Ctrl SAS 6G 5/6
512MB (D2616)
1----1-
3 RAID Ctrl SAS 6G 1GB
(D3116C)
1----1-
4VGA Card
NVIDIA NVS300
1- 1 2 - - -
5USB3.0
Sunrich U-720
1- 1 2 - - -
6 LAN 2x10Gbit Fibre
FTS D2755
2- - - 132
7 LAN 2x10Gbit CU
Intel X540-T2
2- - - 132
8 LAN 2x1Gbit CU
Intel I350-T2
4- 12435
9 LAN 4x1Gbit CU
Intel I350-T4
4- 12435
Order of Install Priority (1..n)
