Fujitsu PRIMERGY TX2540 M1

TX2540 M1 Upgrade and Maintenance Manual 29
Before you start
Phillips
PH2 / (+) No. 2
hexagonal cross
SW5 / PZ2
Backup
drives with
UNC thread
UNC
6-32 x 4.76 mm
(black)
C26192-Y10-C75
Phillips
PH2 / (+) No. 2
USB 3.0
interface
card D3305
M3 x 5 mm
(silver)
(contained in card kit
S26361-D3305-A10)
Phillips
PH0 / (+) No. 0
2.5-inch
HDDs / SSDs
M3 x 3.5 mm
Wafer head screw
(silver)
C26192-Y10-C102
TPM bit insert
Dedicated TPM
screw driver /
TPM fixing tool
(for the Japanese
market)
TPM screw
One way
head
(black)
REM 3 x 15 mm
(black)
C26192-Y10-C176
Phillips
PH1 / (+) No. 1
UFM nylon
screw
M3 x 4.5 mm
(white)
A3C40109082
Phillips
PH1 / (+) No. 1
TFM
M2.5 x 4 mm
(silver)
C26192-Y10-C103
Screw driver /
Bit insert
Screw Usage Type
Table 2: List of required tools and used screws
