Preparing the System for Use
3-44 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Transporting Probes
Secure the probe in its holder for moving short distances.
When transporting a probe a long distance, store it in its carrying
case.
Storing the Probe
It is recommended that all probes be stored in the provided
carrying case or in the wall rack designed for probe storage.
Carrying case:
• First place the probe connector into the carrying case.
• Carefully wind the cable into the carrying case.
• Carefully place the probe head into the carrying case. DO
NOT use excessive force or impact the probe head.
CAUTION
DO NOT store probes in either the side pocket or the peripheral
device’s storage area on the system. To avoid damage, store
the probe in its carrying case.
