Measurement and Calculation Setup
LOGIQ 7 Basic User Manual 7-35
Direction 2392206-100 Rev. 1
Adding Folders and Measurements
Adding a folder
When you add a folder, it can be a study, or a measurement
folder that includes related measurements.
1. In the Selection menu, select the study or folder where you
want to add the folder.
2. In the Measurement menu section, select Add folder.
• If you select Blank, the system adds a folder with a
name such as USERDEFS1. It is listed in the Selection
menu. See Figure 7-20.
• If you want to use an existing folder, select Insert, and
then select a folder from the list. The list includes all
folders defined for the current exam category and
selected mode. You cannot edit this folder.
Figure 7-19. Add folder Window
3. Select the user-defined folder in the Selection menu.
The system displays the new folder in the Folder section of
the Measurement & Analysis screen.
4. To name the folder, move the Trackball to highlight the
Name field, press Set twice, and type the name.
5. To add measurements to the folder, See ‘Adding a user-
defined measurement’ for more information.
