Optimizing the Image
5-24 LOGIQ 7 Online Help
Direction 2392536-100 Rev. 1
Edge Enhance
Description Edge Enhance brings out subtle tissue differences and
boundaries by enhancing the gray scale differences
corresponding to the edges of structures. Adjustments to M-
Mode's edge enhancement affects the M-Mode only.
Adjusting To cycle through settings, adjust Edge Enhance on the Touch
Panel.
Values 0-5, with 0 = Off and 5 = High. The current value displays on the
Touch Panel. Values vary by probe, application, and multi
frequency setting. Values are returned to the preset value when
you change: Probe, Exam Category, Exam Calcs, New Patient,
or Multi Frequency.
Benefits Edge Enhance cleans out the B-Mode image/M-Mode timeline
by subduing some of the gray scale in order to highlight the
vessel wall or organ. This is helpful when you cannot
differentiate between the chambers of the heart.
Affect on other
controls
Edge Enhance operates in realtime only; not in Freeze or CINE.
Rotation (Updown Invert)
Description You can flip the image up/down.
Adjusting To flip the image vertically, press Rotation (up/down).
Values Up/down. Values vary by probe and application. Values are
returned to the preset value when you change: Probe, Exam
Category, Exam Calcs, or New Patient.
Benefits Beneficial in transvaginal and transrectal scanning.
CAUTION
When reading an rotated image, be careful to observe the
probe orientation to avoid possible confusion over scan
direction or left/right image reversal.
