Customizing Your System
16-102 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
System Admin
The System Admin screen has information about any options
implemented for the system.
Figure 16-70. Administrative System Admin Preset Menu
Table 16-61: System Administration
Preset Parameter Description
Product The name of the product.
HW Number The hardware number of the product.
SW Option Key The software option key section.
Enter New Option
Key
Type the key for the option you wish to add and
press Add.
Installed Option Keys Lists the key for the installed options.
Remove To remove a software option key, select the key in
the SW Option Key list, and then select Remove.
Options A list of the option name and status.
Status Lists each option’s effectivity.
