Preparing the System for Use
3-46 LOGIQ 7 Basic User Manual
Direction 2392206-100 Rev. 1
Control Panel Map (continued)
1. Touch panel and controls
2. Touch Panel Brightness Control
3. Video
4. Audio On/Off and Volume
5. TGC
6. Reverse
7. Additional Feature Keys
8. Keyboard
9. Mode/Gain Keys
10. Imaging/Measurement Keys
11. Depth
12. Imaging Feature Keys
13. Freeze and Print Keys
14. Probe and Cord Holder
15. Gel Holder
Key Illumination
All the keys on the front panel, except for the keyboard, and
some rotaries have a two-level backlight capability. The
following backlighting indicates availability.
The keyboard area must have task lighting or equivalent to allow
operation in a dark room.
Table 3-6: Key Illumination
Backlight Capability Availability
OFF Function is not available
ON (Normal-intensity) Function is available
ON (High-intensity) Activated/ON
Blinking User input is requested
