User Maintenance
18-2 LOGIQ 7 Online Help
Direction 2392536-100 Rev. 1
System Data
LOGIQ 7 Features/Specifications
Table 18-1: Physical Attributes
Physical Attributes
Dimensions and Weight
• Height: Minimum 1428 mm (56 in). Maximum 1628
mm (64 in)
• Width: 599 mm (24 in)
• Depth: 999 mm (39 in)
• Weight: approx. 225 kg (500 lb.)
Keyboard
• Keyboard width: 599 mm
• Keyboard Height: 751 mm
• Full alphanumeric keyboard
• Ergonomic hard key operations
• Interactive Back-Lighting
• Task lighting
• 10.4” LCD touch panel
• Integrated recording keys for remote control
• User Define, User Programmable Keys
Electrical Power
• Voltage:100-120 Vac or 220-240 Vac
• Frequency: 50/60 Hz
• Power: Max. 1350 VA with built-in and on-board
peripherals
Console Design
• 4 Active Probe Ports
• Probe connection area designed to allow free
movement of legs
• KBD/Monitor up-down mechanism (200mm
adjustable in height)
• On-board storage for peripherals: Black/white
printer, color printer, VCR.
• Rear Storage Cover for Peripheral Connectors and
Cables
• Probe Holder, removable for cleaning and washing
• Gel Holder, removable for cleaning and washing
• Wheels. Wheel diameter: 150 mm. Rotating
flexible wheels with protective cover. Locking
Mechanism for wheels.
Monitor
• Single 17 High-Resolution monitor Non Interlace
Scan
• SVGA Formats (800x600)
• Tilt/Rotate Adjustable Monitor: Tilt Angle: Up 10°,
Down 10°. Rotate Angle: + 90°.
